Stainless steel fiber yarn

Short Description:

Stainless steel fiber wire are made by stainless steel metal wires drawing into fibers and the form of filaments can be bundle or twisting into mutiply ,due to stainless steel metal properties so it has high temperature resistance and conductive funtions which are widely used in microw cables, heating wire ,high tempterture resistant filter sewing etc , for conductive and heating wire we also sever insulation extrusion offering,outer extrude contents can be FEP,PFA,PTFE,TPU etc,for product more information and inquiring pls check with us.

Send email to us

Product Detail

Product Tags

Products data

Material	High-grade 316L stainless steel filament
FIBER Diameter	Ranges from 8u-14um
Single FiberStrength	≥19cN
Resistance	17-65Ω
Operating temp	500-600℃

Diameters (um)	Filaments	Strength (cN)	Weight (g/m)	Elongation (%)	Conductivity (Ohm/ m)
8	1000F x 1	69	0.420	1.10	16
8	1000F x 2	108	0.850	1.10	8
12	100F x 1	24	0.110	1.10	59
12	100F x 2	41	0.190	1.10	38
12	100F x 3	69	0.280	1.10	22
12	257F x 1	59	0.260	1.10	27
12	275F x 2	75	0.540	1.10	14
12	275F x 3	125	0.780	1.10	9
12	275F x 4	130	1.050	1.10	7
12	275F x 5	160	1.300	1.10	5
12	275F x 6	180	1.500	1.10	4
12	1000F x 1	100	0.950	1.10	7
12	1000F x 2	340	1.900	1.10	4
14	90F x 2	46	0.190	1.10	44
14	90F x 1	25	0.110	1.10

Main feature

Conductive
High temp resistant(working temperature 500-600 ℃ degress)
Heating wire
Reliable and efficient energy and data transfer.
Anti static
Easy to FEP,PFA,PTFE,TPU extrusion
